● The quick and gentle cleaning process is fully automatic and leaves the plates 100% clean and dry within very short time.
● Manual cleaning is easy to damage the printing plate. From a health and safety perspective, this approach is time-consuming and often problematic. The operator's main energy should be devoted to the printing process and printing preparation.
● All types of ink are possible, and this machine is designed for environmentally friendly cleaning.
● The machine is made of stainless steel casing, which is more high-grade and durable.
● After the printing operation is complete, all the printing plates are placed on the conveyor belt, and the printing plate is automatically brought into the whole cleaning process.
● The washing and rinsing series provides an automatic two-stage cleaning process. The first stage is liquid cleaning and the second stage is rinsing with water.
● The liquid is provided with a circulating filtration function.
● The unique combination of a specially manufactured soft brush and a special cleaning solution ensures an efficient and gentle plate cleaning process.
● Water will remove the ink residue and cleaning fluid.
● After hot air drying, the plate can be 100% clean and dry, and can be reused immediately. The whole process only takes a few minutes.
Model | XBJ450 | XBJ650 | XBJ1050 | XBJ1350 | XBJ-1800 |
Maximum plate length(mm) | 450 | 650 | 1050 | 1350 | 1800 |
Machine dimension(mm) | 2350*1100*1150 | 3370*1350*1150 | 3370*1500*1150 | 3370*1920*1150 | 3370*2370*1150 |
voltage | 220v | ||||
Power | 2.7kw | 3.5kw | 4.7kw | 5.5kw | 6.7kw |
Machine weight | 370kg | 450kg | 550kg | 630kg | 720kg |
Fully Automatic Cleaning Process: The Plate Washing Machine automates the entire cleaning cycle, ensuring a fast and efficient cleaning process that leaves plates 100% clean and dry within minutes.
Gentle on Plates: Designed to protect your printing plates, this machine utilizes a soft brush combined with a special cleaning solution to provide a gentle yet thorough cleaning, preventing any damage that might occur with manual cleaning.
Environmentally Friendly: The Plate Washing Machine is designed to accommodate all ink types and utilizes an eco-friendly cleaning process, making it both efficient and sustainable.
Two-Stage Cleaning System: The machine features a dual-phase cleaning process: liquid cleaning followed by a water rinse, ensuring that all ink residues and cleaning agents are completely removed.
Stainless Steel Durability: Built with a stainless steel casing, this machine is not only high-grade but also durable, ensuring long-lasting performance and reliability.
Hot Air Drying: After cleaning and rinsing, hot air is used to dry the plates completely, making them ready for immediate reuse, reducing downtime and enhancing productivity.
Automatic Conveyor Integration: The Plate Washing Machine works seamlessly with an automatic conveyor system, allowing plates to be fed into the machine effortlessly, streamlining the cleaning workflow.
These features combine to ensure that your printing plates are always clean, dry, and ready for the next print cycle with minimal operator intervention.
